Printer Type

4-Colour 24" (610 mm)

Number of Nozzles

4,352 nozzles (BK 1,280 nozzles, C,M,Y: 1,024 nozzles each)

Maximum Print Resolution

2,400 × 1,200 dpi

Nozzle Pitch

1,200 dpi (2 lines)

Line Accuracy^*1

± 0.1% or less

Ink Capacity

Sales Ink: 70 ml (BK, C, M, Y)
Bundled Starter Ink: 70 ml (BK, C, M, Y)

Ink Type

Pigment Ink

Printer Language

SG Raster (Swift Graphic Raster)

PDF
USB Memory [Direct Print]
PDF files created using the ScanToPDF function of the application
PDF files created with MPNavigator, My Image Garden, or IJ Scan Utility

JPEG^*2
Supported Exif ver2.2/2.21/2.3

Printing Solutions

Canon PRINT Inkjet/SELPHY (iOS/Android), Canon Print Service (Android), Free Layout Plus, PosterArtist, Direct Print Plus, PIXUS/PIXMA Cloud Link, ChromeOS

Management Solutions

Media Configuration Tool, Quick Utility Toolbox, Wi-Fi Connection Assistant, Printer Update Utility

Standard Interfaces (Built-in)

USB A Port
USB Memory (Direct Print)
PDF^*3 / JPEG (Exif ver2.2/2.21/2.3)

USB B Port (Series B, 4 pins)
Hi-Speed USB
Full Speed (12 Mbit/sec)
High Speed (480 Mbit/sec)
Bulk Transfer

IEEE 802.3 10base-T
IEEE 802.3u 100base-TX
SNMP, HTTP, TCP/IP (IPv4/IPv6)

Wireless LAN:
IEE802.11a/b/g/n/ac
WPA-PSK (TKIP/AES）
WPA2-PSK (TKIP/AES）
WPA3-SAE (AES)
WPA-EAP (AES)^*4
WPA2-EAP (AES)^*4
WPA3-EAP (AES)^*4

Standard Memory

1 GB

Plain Paper (CAD Drawing)

30 sec (Draft) (Monochrome)

Scanner Type

Flatbed (CIS Scanner)

Optical Resolution (dpi)^*6

1,200 x 2,400 dpi

Greyscale

16 bit / 8 bit

Colour

RGB 16 bit / 8 bit

Greyscale / Monochrome

1.5 ms/line (300 dpi)

Colour

3.5 ms/line (300 dpi)

Maximum Document Size

A4/LTR (216 x 297 mm)

Media Feed and Output

Roll Paper

One Roll, Top Load, Front Output

Cut Sheet

Top Load, Front Output^*7

Media Width (Roll / Cut Sheet)

Roll Width: 297 ~ 610 mm (A3 width to 24");
Cut Sheet Width: 89 ~ 297 mm (A3, A4, Letter, A5, A6)

Media Thickness (Roll / Cut Sheet)

0.08 ～ 0.28 mm

Media Core Size

2 inch core

Min. Printable Length

Roll Paper

203.2 mm

Cut Sheet

127 mm

Max. Printable Length

Roll Paper

4 m^*8

Cut Sheet

1,200 mm

Maximum Outer Roll Diameter

110 mm or less

Borderless Printing Width

NA

Margins (Recommended Area)

Roll Paper

Top/Bottom: 5 mm, Left/Right: 5 mm^*9

Cut Sheet

Top/Bottom: 5 mm, Left/Right: 5 mm

Margins (Printable Area)

Roll Paper

Top/Bottom: 5 mm, Left/Right: 5 mm^*9

Roll Paper (Minimal Margin Print^*10)

Top/Bottom: 0 mm, Left/Right: Approx. 0.5 mm

Cut Sheet

Top/Bottom: 5 mm, Left/Right: 5 mm

Dimensions (W x D x H)

Main Unit

968 × 613 × 395 mm (ASF^*11 Opened, OP^*12 Opened)
968 × 553 × 395 mm (ASF^*11 Opened, OP^*12 Closed)
968 × 593 × 245 mm (ASF^*11 Closed, OP^*12 Opened)
968 × 533 × 245 mm (ASF^*11 Closed, OP^*12 Closed)

Main Unit + Printer Stand + Basket (SD-24)

968 × 868 × 1,024 mm (ASF^*11, OP^*12 & Basket Opened)
968 × 720 × 874 mm (ASF^*11, OP^*12 & Basket Closed)

Main Unit + Desktop Basket (BU-06)

968 × 845 × 1,115^*13 mm (ASF^*11, OP^*12 & Basket Opened)
968 × 595 × 965^*13 mm (ASF^*11, OP^*12 & Basket Closed)

Weight^*14

Main Unit

34 kg

Main Unit + Printer Stand + Basket (SD-24)

44 kg

Main Unit + Desktop Basket (BU-06)

35 kg

Packaged Dimensions (W × D × H)

Main Unit

1,120 × 726 × 406 mm

Stand + Basket (SD-24)

1,058 × 826 × 270 mm

Desktop Basket

798 × 301 × 111 mm

Packaged Weight

Main Unit

46 kg

Stand + Basket (SD-24)

20 kg

Desktop Basket

2.0 kg

Power Supply

AC 100 - 240 V, 50 - 60 Hz

Power Consumption

Copy Operation^*15

Approx. 28 W

Sleep Mode^*15

Approx. 1.7 W

Power Off

Approx. 0.07 W

Operating Environment

Temperature

15 ～ 30°C

Humidity

10 ～ 80% RH (no dew condensation)

Acoustic Sound

Acoustic Power^*16

Operation: Approx. 6.0 Bels

Acoustic Pressure^*16

Operation: Approx. 41.5 dB (A)
Standby: 35 dB (A) or less

Printer Stand (Optional)

SD-24

Desktop Basket

BU-06

Ink Bottle

PFI-050 (70 ml)
Black / Cyan / Magenta / Yellow

Print Head

PF-08

Maintenance Cartridge

MC-32
