High-volume scanning
Built for demanding, high-volume workplaces, Brother’s range of Kofax certified desktop scanners allow busy departments to batch scan and archive a larger number and wider variety of documents quickly and easily. From batch scanning large volumes of very thick or thin paper documents to multi-page, mixed batch media, through to embossed plastic cards, all can be scanned continually with the help of a Separation Switch.

Ultrasonic Multifeed Sensor
The Ultrasonic Multifeed Sensor uses sound waves to identify potential misfeeds and alerts the scanner user to intervene. This reduces the risk of damaged documents and lost data.

Automatically route documents with barcodes
Reduce the labor-intensive task of scanning several documents, saving and then renaming files. Barcode Utility enables documents that have a barcode to be scanned and saved to the required location, automating the separation of a batch of documents and routing each individual file to the designated folder on your network.

Easy Maintenance
Reduced maintenance costs and downtime due to the high-volume scanning capacity and reliable roller mechanisms. Easy access to the paper path allows you to clear any paper jams and the CIS Cleaning Alarm reminds you to clean the unit when required, without having to call a service center.

Basic Specs

• Scanning Speed: 60 ppm
• Document Size - Multiple Sheets - Width: 50.8 mm to 215.9 mm
• • Document Size - Multiple Sheets - Length: 50.8 mm to 355.6 mm
• Document Size - Single Sheet - Width: 50.8 mm to 215.9 mm
• Colour / Monochrome: Yes / Yes
• 2-Sided (Duplex) Scan: Yes
• Colour Depth - Input: 48-bit colour processing
• Colour Depth - Output: 24-bit colour processing
• Resolution - Optical: Up to 600 dpi × 600 dpi
• Resolution - Interpolated: Up to 1,200 dpi × 1,200 dpi
• Document Scanning Width / Length: Up to 215.9 mm
• Product Dimensions (Width X Depth X Height): 300 mm × 236 mm × 247 mm
• Weight: 3.37 kg
• ADF (Automatic Document Feeder): Up to 100 sheets (Paper: 20 lb (80 g/m²) A4/Letter size)
• Memory Capacity: 1024MB

Network • Wireless Network Security: WEP 64/128 bit, WPA-PSK (TKIP/AES), WPA2-PSK (AES), WPA3
• Setup Support Utility: WPS / WLAN Assistant

Display Type
• Touchscreen LCD: 4.3 in. (109.2 mm) TFT colour LCD screen

Operation
• Power Source: AC: 100-240 V, 50/60 Hz
• Power Consumption - Scanning: Approx. 34W
• Power Consumption - Ready: Approx. 7.7W
• Power Consumption - Power Saving / Deep Sleep: Approx. 1.7W
• Power Consumption - Power OFF: Approx. 0.1W
• Temperature Operating: 5°C to 35°C
• Humidity - Operating: 20% to 80%
• Humidity - Storage: 10% to 90%
